Roller Bearings are a type of rolling-element bearing that uses cylinders (rollers) to maintain the separation between the moving parts of the bearing. Compared to ball bearings, roller bearings can support heavy radial loads and limited axial loads.
Roller bearings come in a wide variety of types, designs, series, sizes, variants and materials. We have a wide range of roller bearings in stock from well-renowned brands, including: SKF, NSK, FAG, INA, NTN, TIMKEN, IKO, DEBOT. Click on each below to learn more about each type of roller bearing.
NX35-Z-XL_Needle bearing
NX35-Z-XL_Needle bearing_INA Dimensions: 35 mm x 47 mm x 30 mm, Limiting Speed:12.4 kN r/min, Reference speed:32.5 kNr/min.
- Brand: INA
- Inside Diameter: 35 mm
- Outside Diameter: 47 mm
- Width: 30 mm
- Basic dynamic load rating: 12.4 kN
- Basic static load rating: 32.5 kN
NX25-Z-XL_Needle bearing
NX25-Z-XL_Needle bearing_INA Dimensions: 25 mm x 37 mm x 30 mm, Limiting Speed:11.1 kN r/min, Reference speed:24.3 kNr/min.
- Brand: INA
- Inside Diameter: 25 mm
- Outside Diameter: 37 mm
- Width: 30 mm
- Basic dynamic load rating: 11.1 kN
- Basic static load rating: 24.3 kN
NX17-Z-XL_Needle bearing
NX17-Z-XL_Needle bearing_INA Dimensions: 17 mm x 26 mm x 28 mm, Limiting Speed:5.8 kN r/min, Reference speed:11.5 kNr/min.
- Brand: INA
- Inside Diameter: 17 mm
- Outside Diameter: 26 mm
- Width: 28 mm
- Basic dynamic load rating: 5.8 kN
- Basic static load rating: 11.5 kN
NX12-Z-XL_Needle bearing
NX12-Z-XL_Needle bearing_INA Dimensions: 12 mm x 21 mm x 18 mm, Limiting Speed:4.85 kN r/min, Reference speed:8.2 kNr/min.
- Brand: INA
- Inside Diameter: 12 mm
- Outside Diameter: 21 mm
- Width: 18 mm
- Basic dynamic load rating: 4.85 kN
- Basic static load rating: 8.2 kN
NX10-Z-XL_Needle bearing
NX10-Z-XL_Needle bearing_INA Dimensions: 10 mm x 19 mm x 18 mm, Limiting Speed:4.6 kN r/min, Reference speed:7.2 kNr/min.
- Brand: INA
- Inside Diameter: 10 mm
- Outside Diameter: 19 mm
- Width: 18 mm
- Basic dynamic load rating: 4.6 kN
- Basic static load rating: 7.2 kN
NX7-Z-TV-XL_Needle bearing
NX7-Z-TV-XL_Needle bearing_INA Dimensions: 7 mm x 14 mm x 18 mm, Limiting Speed:3.15 kN r/min, Reference speed:4.3 kNr/min.
- Brand: INA
- Inside Diameter: 7 mm
- Outside Diameter: 14 mm
- Width: 18 mm
- Basic dynamic load rating: 3.15 kN
- Basic static load rating: 4.3 kN
NX20-XL_Needle bearing
NX20-XL_Needle bearing_INA Dimensions: 20 mm x 30 mm x 28 mm, Limiting Speed:7 kN r/min, Reference speed:14.7 kNr/min.
- Brand: INA
- Inside Diameter: 20 mm
- Outside Diameter: 30 mm
- Width: 28 mm
- Basic dynamic load rating: 7 kN
- Basic static load rating: 14.7 kN
NX17-XL_Needle bearing
NX17-XL_Needle bearing_INA Dimensions: 17 mm x 26 mm x 28 mm, Limiting Speed:5.8 kN r/min, Reference speed:11.5 kNr/min.
- Brand: INA
- Inside Diameter: 17 mm
- Outside Diameter: 26 mm
- Width: 28 mm
- Basic dynamic load rating: 5.8 kN
- Basic static load rating: 11.5 kN
NX12-XL_Needle bearing
NX12-XL_Needle bearing_INA Dimensions: 12 mm x 21 mm x 18 mm, Limiting Speed:4.85 kN r/min, Reference speed:8.2 kNr/min.
- Brand: INA
- Inside Diameter: 12 mm
- Outside Diameter: 21 mm
- Width: 18 mm
- Basic dynamic load rating: 4.85 kN
- Basic static load rating: 8.2 kN
NX7-TV-XL_Needle bearing
NX7-TV-XL_Needle bearing_INA Dimensions: 7 mm x 14 mm x 18 mm, Limiting Speed:3.15 kN r/min, Reference speed:4.3 kNr/min.
- Brand: INA
- Inside Diameter: 7 mm
- Outside Diameter: 14 mm
- Width: 18 mm
- Basic dynamic load rating: 3.15 kN
- Basic static load rating: 4.3 kN
