INA NX10-Z-XL Needle bearing
Also known as : NX10-Z-XL
- Inside Diameter: 10 mm
- Outside Diameter: 19 mm
- Width: 18 mm
- Basic dynamic load rating: 4.6 kN
- Basic static load rating: 7.2 kN
INA NX10-Z-XL
INA NX10-Z-XL details
| Number | NX10-Z-XL | |
|---|---|---|
| Type | Needle roller bearings Needle roller/axial ball bearings | |
| Fw | 10 mm | |
| D | 19 mm | |
| C | 18 mm | Tolerance: 0/-0,25 |
| 2) | Mounting dimensions Snap ring in outer ring | |
| C1 | 4,7 mm | |
| C2 | 10 mm | |
| D1 | 21,9 mm | |
| da | 14,6 mm | |
| dw | 10 mm | Tolerance: E8 |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| m | 25 g | Mass |
| Cr | 5000 N | Basic dynamic load rating, radial |
| C0r | 3700 N | Basic static load rating, radial |
| Ca | 4600 N | Basic dynamic load rating, axial |
| C0a | 7200 N | Basic static load rating, axial |
| Cur | 720 N | Fatigue limit load, radial |
| Cua | 320 N | Fatigue limit load, axial |
| nG | 11000 1/min | Limiting speed |
| IR6X10X10-IS1-XL | Suitable inner ring | |
| WR19, SW19 | Suitable snap rings WR and SW |
