Xin You Ya Bearing supplies spherical plain bearings, rod ends, bushings, thrust washers and trips. The brand include SKF, NSK, INA, TIMKEN, IKO.
Plain bearings are manufactured in various designs and with different sliding contact surface combinations. Each design and combination has characteristic properties which makes it particularly suitable for certain applications.
Plain bearings VS ball bearings, VS roller bearing
Many applications require spherical bearings that are suitable for oscillating movements and that can accommodate misalignment. Rolling bearings only partly fulfil these requirements as they are generally designed for continuous rotation and can only accommodate limited misalignment.
Plain bearings can provide an economical solution to these challenges.
GE70-SX_Spherical Plain Bearing
GE70-SX_Spherical Plain Bearing_INA Dimensions: 70 mm x 110 mm x 25 mm, Limiting Speed: 209 kN r/min, Reference speed: 1040 kNr/min.
- Brand: INA
- Inside Diameter: 70 mm
- Outside Diameter: 110 mm
- Width: 25 mm
- Basic dynamic load rating: 209 kN
- Basic static load rating: 1040 kN
GE65-SX_Spherical Plain Bearing
GE65-SX_Spherical Plain Bearing_INA Dimensions: 65 mm x 100 mm x 23 mm, Limiting Speed: 173 kN r/min, Reference speed: 867 kNr/min.
- Brand: INA
- Inside Diameter: 65 mm
- Outside Diameter: 100 mm
- Width: 23 mm
- Basic dynamic load rating: 173 kN
- Basic static load rating: 867 kN
GE60-SX_Spherical Plain Bearing
GE60-SX_Spherical Plain Bearing_INA Dimensions: 60 mm x 95 mm x 23 mm, Limiting Speed: 161 kN r/min, Reference speed: 805 kNr/min.
- Brand: INA
- Inside Diameter: 60 mm
- Outside Diameter: 95 mm
- Width: 23 mm
- Basic dynamic load rating: 161 kN
- Basic static load rating: 805 kN
GE55-SX_Spherical Plain Bearing
GE55-SX_Spherical Plain Bearing_INA Dimensions: 55 mm x 90 mm x 23 mm, Limiting Speed: 149 kN r/min, Reference speed: 746 kNr/min.
- Brand: INA
- Inside Diameter: 55 mm
- Outside Diameter: 90 mm
- Width: 23 mm
- Basic dynamic load rating: 149 kN
- Basic static load rating: 746 kN
GE45-SX_Spherical Plain Bearing
GE45-SX_Spherical Plain Bearing_INA Dimensions: 45 mm x 75 mm x 20 mm, Limiting Speed: 106 kN r/min, Reference speed: 532 kNr/min.
- Brand: INA
- Inside Diameter: 45 mm
- Outside Diameter: 75 mm
- Width: 20 mm
- Basic dynamic load rating: 106 kN
- Basic static load rating: 532 kN
GE40-SX_Spherical Plain Bearing
GE40-SX_Spherical Plain Bearing_INA Dimensions: 40 mm x 68 mm x 19 mm, Limiting Speed: 90.8 kN r/min, Reference speed: 454 kNr/min.
- Brand: INA
- Inside Diameter: 40 mm
- Outside Diameter: 68 mm
- Width: 19 mm
- Basic dynamic load rating: 90.8 kN
- Basic static load rating: 454 kN
GE35-SX_Spherical Plain Bearing
GE35-SX_Spherical Plain Bearing_INA Dimensions: 35 mm x 62 mm x 18 mm, Limiting Speed: 78.6 kN r/min, Reference speed: 393 kNr/min.
- Brand: INA
- Inside Diameter: 35 mm
- Outside Diameter: 62 mm
- Width: 18 mm
- Basic dynamic load rating: 78.6 kN
- Basic static load rating: 393 kN
GE25-SX_Spherical Plain Bearing
GE25-SX_Spherical Plain Bearing_INA Dimensions: 25 mm x 47 mm x 15 mm, Limiting Speed: 47.8 kN r/min, Reference speed: 239 kNr/min.
- Brand: INA
- Inside Diameter: 25 mm
- Outside Diameter: 47 mm
- Width: 15 mm
- Basic dynamic load rating: 47.8 kN
- Basic static load rating: 239 kN
GE25-PW_Spherical Plain Bearing
GE25-PW_Spherical Plain Bearing_INA Dimensions: 25 mm x 47 mm x 31 mm, Limiting Speed: 84.8 kN r/min, Reference speed: 212 kNr/min.
- Brand: INA
- Inside Diameter: 25 mm
- Outside Diameter: 47 mm
- Width: 31 mm
- Basic dynamic load rating: 84.8 kN
- Basic static load rating: 212 kN
GE20-PW_Spherical Plain Bearing
GE20-PW_Spherical Plain Bearing_INA Dimensions: 20 mm x 40 mm x 25 mm, Limiting Speed: 56.6 kN r/min, Reference speed: 141 kNr/min.
- Brand: INA
- Inside Diameter: 20 mm
- Outside Diameter: 40 mm
- Width: 25 mm
- Basic dynamic load rating: 56.6 kN
- Basic static load rating: 141 kN
