Thrust ball bearings are classified into those with flat seats or aligning seats depending on the shape of the outer ring seat (housing washer). They are designed to accommodate axial loads only and must not be subjected to any radial load.
Brand: SKF, NSK, FAG, INA, TIMKEN
Thrust deep groove ball bearings
Thrust angular contact ball bearings
53211-Thrust ball bearings
FAG 53211 Thrust ball bearings, In stock, Dimensions: 55 mm x 90 mm x 27.3 mm, Basic dynamic load rating: 58 kN, Static load rating: 133 kN.
- Brand: FAG
- Inside Diameter: 55 mm
- Outside Diameter: 90 mm
- Width: 27.3 mm
- Basic dynamic load rating: 58 kN
- Basic static load rating: 133 kN
53207-Thrust ball bearings
FAG 53207 Thrust ball bearings, In stock, Dimensions: 35 mm x 62 mm x 19.9 mm, Basic dynamic load rating: 35.5 kN, Static load rating: 67 kN.
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 62 mm
- Width: 19.9 mm
- Basic dynamic load rating: 35.5 kN
- Basic static load rating: 67 kN
53206-Thrust ball bearings
FAG 53206 Thrust ball bearings, In stock, Dimensions: 30 mm x 52 mm x 17.8 mm, Basic dynamic load rating: 23.9 kN, Static load rating: 46 kN.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 52 mm
- Width: 17.8 mm
- Basic dynamic load rating: 23.9 kN
- Basic static load rating: 46 kN
53205-Thrust ball bearings
FAG 53205 Thrust ball bearings, In stock, Dimensions: 25 mm x 47 mm x 16.7 mm, Basic dynamic load rating: 26.5 kN, Static load rating: 50 kN.
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 47 mm
- Width: 16.7 mm
- Basic dynamic load rating: 26.5 kN
- Basic static load rating: 50 kN
53204-Thrust ball bearings
FAG 53204 Thrust ball bearings, In stock, Dimensions: 20 mm x 40 mm x 14.7 mm, Basic dynamic load rating: 21.1 kN, Static load rating: 37.5 kN.
- Brand: FAG
- Inside Diameter: 20 mm
- Outside Diameter: 40 mm
- Width: 14.7 mm
- Basic dynamic load rating: 21.1 kN
- Basic static load rating: 37.5 kN
51106-Thrust ball bearings
FAG 51106 Thrust ball bearings, In stock, Dimensions: 30 mm x 47 mm x 11 mm, Basic dynamic load rating: 18.8 kN, Static load rating: 40 kN.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 47 mm
- Width: 11 mm
- Basic dynamic load rating: 18.8 kN
- Basic static load rating: 40 kN
53203-Thrust ball bearings
FAG 53203 Thrust ball bearings, In stock, Dimensions: 17 mm x 35 mm x 13.2 mm, Basic dynamic load rating: 17.2 kN, Static load rating: 27.5 kN.
- Brand: FAG
- Inside Diameter: 17 mm
- Outside Diameter: 35 mm
- Width: 13.2 mm
- Basic dynamic load rating: 17.2 kN
- Basic static load rating: 27.5 kN
53202-Thrust ball bearings
FAG 53202 Thrust ball bearings, In stock, Dimensions: 15 mm x 32 mm x 13.3 mm, Basic dynamic load rating: 16.6 kN, Static load rating: 24.8 kN.
- Brand: FAG
- Inside Diameter: 15 mm
- Outside Diameter: 32 mm
- Width: 13.3 mm
- Basic dynamic load rating: 16.6 kN
- Basic static load rating: 24.8 kN
53201-Thrust ball bearings
FAG 53201 Thrust ball bearings, In stock, Dimensions: 12 mm x 28 mm x 11.4 mm, Basic dynamic load rating: 13.2 kN, Static load rating: 19 kN.
- Brand: FAG
- Inside Diameter: 12 mm
- Outside Diameter: 28 mm
- Width: 11.4 mm
- Basic dynamic load rating: 13.2 kN
- Basic static load rating: 19 kN
53200-Thrust ball bearings
FAG 53200 Thrust ball bearings, In stock, Dimensions: 10 mm x 26 mm x 11.6 mm, Basic dynamic load rating: 12.7 kN, Static load rating: 17.1 kN.
- Brand: FAG
- Inside Diameter: 10 mm
- Outside Diameter: 26 mm
- Width: 11.6 mm
- Basic dynamic load rating: 12.7 kN
- Basic static load rating: 17.1 kN
51103-Thrust ball bearings
FAG 51103 Thrust ball bearings, In stock, Dimensions: 17 mm x 30 mm x 9 mm, Basic dynamic load rating: 11.3 kN, Static load rating: 19.6 kN.
- Brand: FAG
- Inside Diameter: 17 mm
- Outside Diameter: 30 mm
- Width: 9 mm
- Basic dynamic load rating: 11.3 kN
- Basic static load rating: 19.6 kN
ZKLN50110-2RS-XL-Thrust ball bearings
INA ZKLN50110-2RS-XL Thrust ball bearings, In stock, Dimensions: 50 mm x 110 mm x 54 mm, Basic dynamic load rating: 125 kN, Static load rating: 250 kN.
- Brand: INA
- Inside Diameter: 50 mm
- Outside Diameter: 110 mm
- Width: 54 mm
- Basic dynamic load rating: 125 kN
- Basic static load rating: 250 kN
ZKLN4090-2RS-XL-Thrust ball bearings
INA ZKLN4090-2RS-XL Thrust ball bearings, In stock, Dimensions: 40 mm x 90 mm x 46 mm, Basic dynamic load rating: 79 kN, Static load rating: 149 kN.
- Brand: INA
- Inside Diameter: 40 mm
- Outside Diameter: 90 mm
- Width: 46 mm
- Basic dynamic load rating: 79 kN
- Basic static load rating: 149 kN
ZKLN3572-2RS-XL-Thrust ball bearings
INA ZKLN3572-2RS-XL Thrust ball bearings, In stock, Dimensions: 35 mm x 72 mm x 34 mm, Basic dynamic load rating: 45 kN, Static load rating: 89 kN.
- Brand: INA
- Inside Diameter: 35 mm
- Outside Diameter: 72 mm
- Width: 34 mm
- Basic dynamic load rating: 45 kN
- Basic static load rating: 89 kN
ZKLF1560-2RS-XL-Thrust ball bearings
INA ZKLF1560-2RS-XL Thrust ball bearings, In stock, Dimensions: 15 mm x 60 mm x 25 mm, Basic dynamic load rating: 19.6 kN, Static load rating: 28 kN.
- Brand: INA
- Inside Diameter: 15 mm
- Outside Diameter: 60 mm
- Width: 25 mm
- Basic dynamic load rating: 19.6 kN
- Basic static load rating: 28 kN
ZKLN1545-2RS-XL-Thrust ball bearings
INA ZKLN1545-2RS-XL Thrust ball bearings, In stock, Dimensions: 15 mm x 45 mm x 25 mm, Basic dynamic load rating: 19.6 kN, Static load rating: 28 kN.
- Brand: INA
- Inside Diameter: 15 mm
- Outside Diameter: 45 mm
- Width: 25 mm
- Basic dynamic load rating: 19.6 kN
- Basic static load rating: 28 kN
ZKLN0832-2RS-XL-Thrust ball bearings
INA ZKLN0832-2RS-XL Thrust ball bearings, In stock, Dimensions: 8 mm x 32 mm x 20 mm, Basic dynamic load rating: 13.8 kN, Static load rating: 16.3 kN.
- Brand: INA
- Inside Diameter: 8 mm
- Outside Diameter: 32 mm
- Width: 20 mm
- Basic dynamic load rating: 13.8 kN
- Basic static load rating: 16.3 kN
ZKLF50140-2RS-XL-Thrust ball bearings
INA ZKLF50140-2RS-XL Thrust ball bearings, In stock, Dimensions: 50 mm x 140 mm x 54 mm, Basic dynamic load rating: 125 kN, Static load rating: 250 kN.
- Brand: INA
- Inside Diameter: 50 mm
- Outside Diameter: 140 mm
- Width: 54 mm
- Basic dynamic load rating: 125 kN
- Basic static load rating: 250 kN
ZKLF40115-2RS-XL-Thrust ball bearings
INA ZKLF40115-2RS-XL Thrust ball bearings, In stock, Dimensions: 40 mm x 115 mm x 46 mm, Basic dynamic load rating: 79 kN, Static load rating: 149 kN.
- Brand: INA
- Inside Diameter: 40 mm
- Outside Diameter: 115 mm
- Width: 46 mm
- Basic dynamic load rating: 79 kN
- Basic static load rating: 149 kN
ZKLF3590-2RS-XL-Thrust ball bearings
INA ZKLF3590-2RS-XL Thrust ball bearings, In stock, Dimensions: 35 mm x 90 mm x 34 mm, Basic dynamic load rating: 45 kN, Static load rating: 89 kN.
- Brand: INA
- Inside Diameter: 35 mm
- Outside Diameter: 90 mm
- Width: 34 mm
- Basic dynamic load rating: 45 kN
- Basic static load rating: 89 kN
