FAG 11212-TVH

FAG 11212-TVH Aligning ball bearing

Also known as : 11212-TVH

Inside Diameter: 60 mm
Outside Diameter: 110 mm
Width: 62 mm
Basic dynamic load rating: 30.5 kN
Basic static load rating: 11.4 kN

FAG 11212-TVH

FAG 11212-TVH details

d	60 mm
D	110 mm
B_i	62 mm
B	22 mm
D₁	95,2 mm
D_{a max}	101 mm
d₁	78 mm
r_{a max}	1,5 mm
r_min	1,5 mm
m	1,5 kg	Mass
C_r	30500 N	Basic dynamic load rating, radial
C_0r	11400 N	Basic static load rating, radial
e	0,18
Y₁	3,47
Y₂	5,37
Y₀	3,64
C_ur	710 N	Fatigue limit load, radial
n_G	6900 1/min	Limiting speed
n_B	6300 1/min	Reference speed

FAG 11212-TVH bearing cross reference

11212-TVH
60 mmx 110 mmx 62 mm

11211-TVH
60 mmx 110 mmx 62 mm

11210-TVH
60 mmx 110 mmx 62 mm

11209-TVH
60 mmx 110 mmx 62 mm

11207-TVH
60 mmx 110 mmx 62 mm

11206-TVH
60 mmx 110 mmx 62 mm

11205-TVH
60 mmx 110 mmx 62 mm

11204-TVH
60 mmx 110 mmx 62 mm

2311-2RS-TVH
60 mmx 110 mmx 62 mm

2310-2RS-TVH
60 mmx 110 mmx 62 mm

2309-2RS-TVH
60 mmx 110 mmx 62 mm

2308-2RS-TVH
60 mmx 110 mmx 62 mm
