FAG 11210-TVH

FAG 11210-TVH Aligning ball bearing

Also known as : 11210-TVH

Inside Diameter: 50 mm
Outside Diameter: 90 mm
Width: 58 mm
Basic dynamic load rating: 22.9 kN
Basic static load rating: 8 kN

FAG 11210-TVH

FAG 11210-TVH details

d	50 mm
D	90 mm
B_i	58 mm
B	20 mm
D₁	77,1 mm
D_{a max}	83 mm
d₁	62,7 mm
r_{a max}	1 mm
r_min	1,1 mm
m	0,85 kg	Mass
C_r	22900 N	Basic dynamic load rating, radial
C_0r	8000 N	Basic static load rating, radial
e	0,2
Y₁	3,17
Y₂	4,9
Y₀	3,32
C_ur	500 N	Fatigue limit load, radial
n_G	8700 1/min	Limiting speed
n_B	7700 1/min	Reference speed
