FAG 2212-K-2RS-TVH-C3 Aligning ball bearing
Also known as : 2212-K-2RS-TVH-C3
- Inside Diameter: 60 mm
- Outside Diameter: 110 mm
- Width: 28 mm
- Basic dynamic load rating: 30.5 kN
- Basic static load rating: 11.4 kN
FAG 2212-K-2RS-TVH-C3
FAG 2212-K-2RS-TVH-C3 details
| d | 60 mm | |
|---|---|---|
| D | 110 mm | |
| B | 28 mm | |
| D2 | 99,5 mm | |
| Da max | 101 mm | |
| d2 | 70,4 mm | |
| da max | 75 mm | |
| da min | 69 mm | |
| ra max | 1,5 mm | |
| rmin | 1,5 mm | |
| m | 1,13 kg | Mass |
| Cr | 30500 N | Basic dynamic load rating, radial |
| C0r | 11400 N | Basic static load rating, radial |
| e | 0,18 | |
| Y1 | 3,47 | |
| Y2 | 5,37 | |
| Y0 | 3,64 | |
| nG | 3450 1/min | Limiting speed |
| Cur | 710 N | Fatigue limit load, radial |
| H312 | Designation, adapter sleeve |
FAG 2212-K-2RS-TVH-C3 bearing cross reference
11212-TVH
60 mmx 110 mmx 28 mm
11211-TVH
60 mmx 110 mmx 28 mm
11210-TVH
60 mmx 110 mmx 28 mm
11209-TVH
60 mmx 110 mmx 28 mm
11207-TVH
60 mmx 110 mmx 28 mm
11206-TVH
60 mmx 110 mmx 28 mm
11205-TVH
60 mmx 110 mmx 28 mm
11204-TVH
60 mmx 110 mmx 28 mm
2311-2RS-TVH
60 mmx 110 mmx 28 mm
2310-2RS-TVH
60 mmx 110 mmx 28 mm
2309-2RS-TVH
60 mmx 110 mmx 28 mm
