INA 89318-M Thrust roller bearings
Also known as : 89318-M
- Inside Diameter: 90 mm
- Outside Diameter: 155 mm
- Width: 39 mm
- Basic dynamic load rating: 335 kN
- Basic static load rating: 1200 kN
INA 89318-M
INA 89318-M details
| Number | 89318-M | |
|---|---|---|
| Type | Thrust roller bearings | |
| d | 90 mm | |
| D | 155 mm | |
| T | 39 mm | |
| D1 | 93 mm | |
| Da max | 98 mm | |
| d1 | 155 mm | |
| da min | 152 mm | |
| ra max | 1,5 mm | |
| rmin | 1,5 mm | |
| m | 3,63 kg | Mass |
| Ca | 335000 N | Basic dynamic load rating, axial |
| C0a | 1200000 N | Basic static load rating, axial |
| Cua | 109000 N | Fatigue limit load |
| nG | 2350 1/min | Limiting speed |
| nB | 980 1/min | Reference speed |
| K89318-M | Allocated axial cylindrical roller and cage assembly | |
| GS89318 | Allocated housing locating washer | |
| WS89318 | Allocated shaft locating washer |
