INA SL045005-PP Cylindrical roller bearing
Also known as : SL045005-PP,NNF5005ADA-2LSV
- Inside Diameter: 25 mm
- Outside Diameter: 47 mm
- Width: 30 mm
- Basic dynamic load rating: 46 kN
- Basic static load rating: 60 kN
INA SL045005-PP
INA SL045005-PP details
| model | SL045005-PP |
|---|---|
| d | 25 mm |
| D | 47 mm |
| B | 30 mm |
| Chamfer angle | 30 ° |
| C | 29 mm |
| C1 | 24.7 mm |
| Ca1 | 21.5 mm |
| Ca2 | 21 mm |
| D1 | 45.2 mm |
| d1 | 35.35 mm |
| d2 | 39 mm |
| d3 | 52 mm |
| m | 1.8 mm |
| rmin | 0.3 mm |
| t | 0.5 mm |
| X | 22.5 mm |
| Cr | 46000 N |
| C0r | 60000 N |
| Cur | 8100 N, Fatigue limit load, radial |
| Limiting speed | 4700 1/min |
| mass | 0.24 kg |
