INA SL181856-E Cylindrical roller bearing
Also known as : SL181856-E,NCF1856V
- Inside Diameter: 280 mm
- Outside Diameter: 350 mm
- Width: 33 mm
- Basic dynamic load rating: 355 kN
- Basic static load rating: 670 kN
INA SL181856-E
INA SL181856-E details
| model | SL181856-E |
|---|---|
| d | 280 mm |
| D | 350 mm |
| B | 33 mm |
| D1 | 327 mm |
| d1 | 304 mm |
| E | 335 mm |
| rmin | 2 mm |
| s | 2.5 mm, Axial displacement |
| Cr | 355000 N |
| C0r | 670000 N |
| Cur | 73000 N, Fatigue limit load, radial |
| Reference speed | 730 1/min |
| Limiting speed | 990 1/min |
| mass | 6.89 kg |
INA SL181856-E bearing cross reference
NN30/500-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3092-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3088-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3084-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3076-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3072-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3064-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3044-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3040-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3034-AS-K-M-SP
280 mmx 350 mmx 33 mm
NN3032-AS-K-M-SP
280 mmx 350 mmx 33 mm
