INA SL181888-E Cylindrical roller bearing
Also known as : SL181888-E,NCF1888V
- Inside Diameter: 440 mm
- Outside Diameter: 540 mm
- Width: 46 mm
- Basic dynamic load rating: 700 kN
- Basic static load rating: 1470 kN
INA SL181888-E
INA SL181888-E details
| model | SL181888-E |
|---|---|
| d | 440 mm |
| D | 540 mm |
| B | 46 mm |
| D1 | 506 mm |
| d1 | 473.5 mm |
| E | 517 mm |
| rmin | 2.1 mm |
| s | 4 mm, Axial displacement |
| Cr | 700000 N |
| C0r | 1470000 N |
| Cur | 145000 N, Fatigue limit load, radial |
| Reference speed | 415 1/min |
| Limiting speed | 620 1/min |
| mass | 21.54 kg |
INA SL181888-E bearing cross reference
NN30/500-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3092-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3088-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3084-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3076-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3072-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3064-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3044-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3040-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3034-AS-K-M-SP
440 mmx 540 mmx 46 mm
NN3032-AS-K-M-SP
440 mmx 540 mmx 46 mm
