INA SL045028-PP Cylindrical roller bearing
Also known as : SL045028-PP, NNF5028-ADA-2LSV
- Inside Diameter: 140 mm
- Outside Diameter: 210 mm
- Width: 95 mm
- Basic dynamic load rating: 610 kN
- Basic static load rating: 1100 kN
INA SL045028-PP
INA SL045028-PP details
| model | SL045028-PP |
|---|---|
| d | 140 mm |
| D | 210 mm |
| B | 95 mm |
| Chamfer angle | 30 ° |
| C | 94 mm |
| C1 | 83.2 mm |
| Ca1 | 77 mm |
| Ca2 | 73 mm |
| D1 | 206 mm |
| d1 | 165.4 mm |
| d2 | 181 mm |
| d3 | 226 mm |
| m | 5.2 mm |
| rmin | 0.6 mm |
| t | 1.8 mm |
| X | 77 mm |
| Cr | 610000 N |
| C0r | 1100000 N |
| Cur | 146000 N, Fatigue limit load, radial |
| Limiting speed | 910 1/min |
| mass | 11.1 kg |
INA SL045028-PP bearing cross reference
NN30/500-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3092-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3088-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3084-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3076-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3072-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3064-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3044-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3040-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3034-AS-K-M-SP
140 mmx 210 mmx 95 mm
NN3032-AS-K-M-SP
140 mmx 210 mmx 95 mm
