NSK NJ336EM Cylindrical roller bearing
Also known as : NJ336EM, NJ336M
- Inside Diameter: 180 mm
- Outside Diameter: 380 mm
- Width: 75 mm
- Basic dynamic load rating: 985 kN
- Basic static load rating: 1230 kN
NSK NJ336EM
NSK NJ336EM details
| model | NJ336EM |
|---|---|
| d | 180 mm |
| D | 380 mm |
| B | 75 mm |
| rmin. | 4.0 mm |
| r1 min. | 4.0 mm |
| Fw | 231.0 mm |
| Cr | 985 kN, Basic dynamic Load Ratings |
| C0r | 1230 kN, Basic static Load Ratings |
|
Limiting speeds Thermal Reference |
1700 min-1 |
|
Limiting speeds Mechanical |
2800 min-1 |
|
Limiting speeds Grease |
1500 min-1 |
|
Limiting speeds Oil |
1800 min-1 |
| Mass | 44 kg (approx.) |
NSK NJ336EM bearing cross reference
NN30/500-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3092-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3088-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3084-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3076-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3072-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3064-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3044-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3040-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3034-AS-K-M-SP
180 mmx 380 mmx 75 mm
NN3032-AS-K-M-SP
180 mmx 380 mmx 75 mm
