NSK 7328BDT

NSK 7328BDT Angular contact ball bearings

Also known as : 7328BDT

Inside Diameter: 140 mm
Outside Diameter: 300 mm
Width: 62 mm
Basic dynamic load rating: 445 kN
Basic static load rating: 615 kN

NSK 7328BDT

NSK 7328BDT details

model	7328BDT
d	140 mm
D	300 mm
B	62 mm
2B	124 mm
r_min.	4.0 mm
r_{1 min.}	1.50 mm
C_r	445000 N 45500 kgf
C_0r	615000 N 63000 kgf
Limiting speeds	1400 min^-1 (Grease)
Limiting speeds	1900 min^-1 (Oil)
d_a	158.0 mm
D_a	282.0 mm
r_a	3.0 mm
Mass	21.6 kg (approx.)

NSK 7328BDT bearing cross reference

30/5-B-2Z-TVH
140 mmx 300 mmx 62 mm

3806-B-2RS-TVH
140 mmx 300 mmx 62 mm

3801-B-2RS-TVH
140 mmx 300 mmx 62 mm

3217-B-2RS-TVH
140 mmx 300 mmx 62 mm

3313-BD-XL
140 mmx 300 mmx 62 mm

3311-BD-XL
140 mmx 300 mmx 62 mm

3310-BD-XL-TVH
140 mmx 300 mmx 62 mm

3310-BD-XL
140 mmx 300 mmx 62 mm

3309-BD-XL
140 mmx 300 mmx 62 mm

3307-BD-XL
140 mmx 300 mmx 62 mm

3306-BD-XL
140 mmx 300 mmx 62 mm

3305-BD-XL
140 mmx 300 mmx 62 mm
