NSK 7313B

NSK 7313B Angular contact ball bearings

Also known as : 7313B

Inside Diameter: 65 mm
Outside Diameter: 140 mm
Width: 33 mm
Basic dynamic load rating: 102 kN
Basic static load rating: 75.5 kN

NSK 7313B

NSK 7313B details

model	7313B
d	65 mm
D	140 mm
B	33 mm
a	59.5 mm
r_min.	2.1 mm
r_{1 min.}	1.10 mm
C_r	102000 N 10400 kgf
C_0r	75500 N 7700 kgf
Limiting speeds	3800 min^-1 (Grease)
Limiting speeds	5300 min^-1 (Oil)
d_a	77.0 mm
D_a	128.0 mm
r_a	2.0 mm
Mass	2.170 kg (approx.)

NSK 7313B bearing cross reference

30/5-B-2Z-TVH
65 mmx 140 mmx 33 mm

3806-B-2RS-TVH
65 mmx 140 mmx 33 mm

3801-B-2RS-TVH
65 mmx 140 mmx 33 mm

3217-B-2RS-TVH
65 mmx 140 mmx 33 mm

3313-BD-XL
65 mmx 140 mmx 33 mm

3311-BD-XL
65 mmx 140 mmx 33 mm

3310-BD-XL-TVH
65 mmx 140 mmx 33 mm

3310-BD-XL
65 mmx 140 mmx 33 mm

3309-BD-XL
65 mmx 140 mmx 33 mm

3307-BD-XL
65 mmx 140 mmx 33 mm

3306-BD-XL
65 mmx 140 mmx 33 mm

3305-BD-XL
65 mmx 140 mmx 33 mm
