INA NKXR20-XL Needle bearing
Also known as : NKXR20-XL
- Inside Diameter: 20 mm
- Outside Diameter: 30 mm
- Width: 30 mm
- Basic dynamic load rating: 25 kN
- Basic static load rating: 53 kN
INA NKXR20-XL
INA NKXR20-XL details
| Number | NKXR20-XL | |
|---|---|---|
| Type | Needle roller bearings Needle roller/axial cylindrical roller bearings | |
| Fw | 20 mm | |
| D | 30 mm | |
| C | 30 mm | Tolerance: 0/-0,25 |
| C1 | 10 mm | Tolerance: 0/-0,2 |
| C2 | 10,5 mm | |
| D1 max | 35,1 mm | |
| da | 30,7 mm | |
| dw | 20 mm | Tolerance: E8 |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| m | 80 g | Mass |
| Cr | 18600 N | Basic dynamic load rating, radial |
| C0r | 23800 N | Basic static load rating, radial |
| Ca | 25000 N | Basic dynamic load rating, axial |
| C0a | 53000 N | Basic static load rating, axial |
| Cur | 4150 N | Fatigue limit load, radial |
| Cua | 7300 N | Fatigue limit load, axial |
| nG | 10000 1/min | Limiting speed |
| nB | 4200 1/min | Reference speed |
| IR17X20X20-XL | Suitable inner ring |
