INA RNAO20X28X26-ZW-ASR1-XL Needle bearing
Also known as : RNAO20X28X26-ZW-ASR1-XL, RNAFW202826
- Inside Diameter: 20 mm
- Outside Diameter: 28 mm
- Width: 26 mm
- Basic dynamic load rating: 19 kN
- Basic static load rating: 28.5 kN
INA RNAO20X28X26-ZW-ASR1-XL
INA RNAO20X28X26-ZW-ASR1-XL details
| Fw | 20 mm | |
|---|---|---|
| D | 28 mm | |
| C | 26 mm | |
| Da | 24,3 mm | |
| Db | 20,4 mm | |
| db | 23,6 mm | |
| E | 24 mm | |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| m | 50 g | Mass |
| Cr | 19000 N | Basic dynamic load rating, radial |
| C0r | 28500 N | Basic static load rating, radial |
| Cur | 4600 N | Fatigue limit load, radial |
| nG | 21300 1/min | Limiting speed |
| nB | 13700 1/min | Reference speed |
INA RNAO20X28X26-ZW-ASR1-XL bearing cross reference
YTL 2526
20 mmx 28 mmx26 mm
YT 2515
20 mmx 28 mmx26 mm
YT 243216
20 mmx 28 mmx26 mm
YT 2428
20 mmx 28 mmx26 mm
YT 223016
20 mmx 28 mmx26 mm
YT 2116
20 mmx 28 mmx26 mm
YT 2025
20 mmx 28 mmx26 mm
YT 1715
20 mmx 28 mmx26 mm
TAMW 7050
20 mmx 28 mmx26 mm
TAM 7040
20 mmx 28 mmx26 mm
TAM 7030
20 mmx 28 mmx26 mm
