INA RNAO18X30X24-ZW-ASR1-XL Needle bearing
Also known as : RNAO18X30X24-ZW-ASR1-XL, RNAFW183024
- Inside Diameter: 18 mm
- Outside Diameter: 30 mm
- Width: 24 mm
- Basic dynamic load rating: 24.8 kN
- Basic static load rating: 30 kN
INA RNAO18X30X24-ZW-ASR1-XL
INA RNAO18X30X24-ZW-ASR1-XL details
| Fw | 18 mm | |
|---|---|---|
| D | 30 mm | |
| C | 24 mm | |
| Da | 24,5 mm | |
| Db | 18,4 mm | |
| db | 23,6 mm | |
| E | 24 mm | |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| m | 69 g | Mass |
| Cr | 24800 N | Basic dynamic load rating, radial |
| C0r | 30000 N | Basic static load rating, radial |
| Cur | 5300 N | Fatigue limit load, radial |
| nG | 21800 1/min | Limiting speed |
| nB | 14000 1/min | Reference speed |
INA RNAO18X30X24-ZW-ASR1-XL bearing cross reference
YTL 2526
18 mmx 30 mmx24 mm
YT 2515
18 mmx 30 mmx24 mm
YT 243216
18 mmx 30 mmx24 mm
YT 2428
18 mmx 30 mmx24 mm
YT 223016
18 mmx 30 mmx24 mm
YT 2116
18 mmx 30 mmx24 mm
YT 2025
18 mmx 30 mmx24 mm
YT 1715
18 mmx 30 mmx24 mm
TAMW 7050
18 mmx 30 mmx24 mm
TAM 7040
18 mmx 30 mmx24 mm
TAM 7030
18 mmx 30 mmx24 mm
