INA NKI7/12-TV-XL Needle bearing
Also known as : NKI7/12-TV-XL
- Inside Diameter: 7 mm
- Outside Diameter: 17 mm
- Width: 12 mm
- Basic dynamic load rating: 5.3 kN
- Basic static load rating: 5.5 kN
INA NKI7/12-TV-XL
INA NKI7/12-TV-XL details
| d | 7 mm | |
|---|---|---|
| D | 17 mm | |
| B | 12 mm | |
| F | 10 mm | |
| rmin | 0,3 mm | |
| s | 1,5 mm | Axial displacement |
| m | 13,7 g | Mass |
| Cr | 5300 N | Basic dynamic load rating, radial |
| C0r | 5500 N | Basic static load rating, radial |
| Cur | 930 N | Fatigue limit load, radial |
| nG | 29500 1/min | Limiting speed |
| nB | 26000 1/min | Reference speed |
| With closing rings, without lubrication hole and without lubrication groove. |
INA NKI7/12-TV-XL bearing cross reference
YTL 2526
7 mmx 17 mmx12 mm
YT 2515
7 mmx 17 mmx12 mm
YT 243216
7 mmx 17 mmx12 mm
YT 2428
7 mmx 17 mmx12 mm
YT 223016
7 mmx 17 mmx12 mm
YT 2116
7 mmx 17 mmx12 mm
YT 2025
7 mmx 17 mmx12 mm
YT 1715
7 mmx 17 mmx12 mm
TAMW 7050
7 mmx 17 mmx12 mm
TAM 7040
7 mmx 17 mmx12 mm
TAM 7030
7 mmx 17 mmx12 mm
