INA NKXR45-Z-XL Needle bearing
Also known as : NKXR45-Z-XL
- Inside Diameter: 45 mm
- Outside Diameter: 58 mm
- Width: 32 mm
- Basic dynamic load rating: 59 kN
- Basic static load rating: 163 kN
INA NKXR45-Z-XL
INA NKXR45-Z-XL details
| Number | NKXR45-Z-XL | |
|---|---|---|
| Type |
Needle roller bearings Needle roller/axial cylindrical roller bearings |
|
| Fw | 45 mm | |
| D | 58 mm | |
| C | 32 mm | Tolerance: 0/-0,25 |
| C1 | 14 mm | Tolerance: 0/-0,2 |
| C2 | 9 mm | |
| D2 max | 66,5 mm | |
| da | 60,6 mm | |
| dw | 45 mm | Tolerance: E8 |
| ra max | 0,6 mm | |
| rmin | 0,6 mm | |
| m | 260 g | Mass |
| Cr | 31000 N | Basic dynamic load rating, radial |
| C0r | 53000 N | Basic static load rating, radial |
| Ca | 59000 N | Basic dynamic load rating, axial |
| C0a | 163000 N | Basic static load rating, axial |
| Cur | 9300 N | Fatigue limit load, radial |
| Cua | 16000 N | Fatigue limit load, axial |
| nG | 5000 1/min | Limiting speed |
| nB | 1900 1/min | Reference speed |
| IR40X45X20-XL | Suitable inner ring |
