TIMKEN 314K

TIMKEN 314K Deep groove ball bearings

Also known as : 314K

Inside Diameter: 70 mm
Outside Diameter: 150 mm
Width: 35 mm
Basic dynamic load rating: 116 kN
Basic static load rating: 67.9 kN

TIMKEN 314K

TIMKEN 314K details

Bearing Number	314K
Brand	TIMKEN
Type	Deep groove ball bearings
Design Units	METRIC
Ball Type	Steel
Bearing Weight	2.617 Kg 5.77 lb
d - Bore	70.000 mm 2.7559 in
D - Outer Diameter	150.000 mm 5.9055 in
Bearing Width	35.000 mm 1.3780 in
do - Ball Diameter	25.40000 mm 1.00000 in
Ce - Dynamic Radial Rating¹	116000 N 26000 lbf
C0 - Static Radial Rating	67900 N 15300 lbf
Limiting Speed (Grease)	2730 rpm
Limiting Speed (Oil)	3180 rpm
R - Inner Ring "To Clear" Radius²	2.110 mm 0.083 in
r - Outer Ring "To Clear" Radius³	2.110 mm 0.083 in
da - Inner Ring Backing Diameter	82.000 mm 3.230 in
Da - Outer Ring Backing Diameter	137.900 mm 5.430 in

TIMKEN 314K bearing cross reference

302K
70 mmx 150 mmx 35 mm

301K
70 mmx 150 mmx 35 mm

62207-2RS-C3
70 mmx 150 mmx 35 mm

62306-2RS-C3
70 mmx 150 mmx 35 mm

63005-2RS-C3
70 mmx 150 mmx 35 mm

62205-2RS-C3
70 mmx 150 mmx 35 mm

62304-2RS-C3
70 mmx 150 mmx 35 mm

62204-2RS-C3
70 mmx 150 mmx 35 mm

63003-2RS-C3
70 mmx 150 mmx 35 mm

62303-2RS-C3
70 mmx 150 mmx 35 mm

63002-2RS-C3
70 mmx 150 mmx 35 mm

62302-2RS-C3
70 mmx 150 mmx 35 mm
