NSK 60/630 Deep groove ball bearings
Also known as : 60/630
- Inside Diameter: 630 mm
- Outside Diameter: 920 mm
- Width: 128 mm
- Basic dynamic load rating: 750000 kN
- Basic static load rating: 1620000 kN
NSK 60/630
NSK 60/630 details
| model | 60/630 |
|---|---|
| d | 630 mm |
| D | 920 mm |
| B | 128 mm |
| rmin. | 7.5 mm |
| Cr |
750000 N 76500 kgf |
| C0r |
1620000 N 165000 kgf |
| Limiting speeds | 480 min-1 (Grease) |
| Limiting speeds | 600 min-1 (Oil) |
| f0 | 16.4 (Factor) |
| da min | 662.0 mm |
| da max | 0.0 mm |
| Da | 888.0 mm |
| ra | 6.0 mm |
| Mass | 285.000 kg (approx.) |
NSK 60/630 bearing cross reference
302K
630 mmx 920 mmx 128 mm
301K
630 mmx 920 mmx 128 mm
62207-2RS-C3
630 mmx 920 mmx 128 mm
62306-2RS-C3
630 mmx 920 mmx 128 mm
63005-2RS-C3
630 mmx 920 mmx 128 mm
62205-2RS-C3
630 mmx 920 mmx 128 mm
62304-2RS-C3
630 mmx 920 mmx 128 mm
62204-2RS-C3
630 mmx 920 mmx 128 mm
63003-2RS-C3
630 mmx 920 mmx 128 mm
62303-2RS-C3
630 mmx 920 mmx 128 mm
63002-2RS-C3
630 mmx 920 mmx 128 mm
