NSK 6222 Deep groove ball bearings
Also known as : 6222
- Inside Diameter: 110 mm
- Outside Diameter: 200 mm
- Width: 38 mm
- Basic dynamic load rating: 144 kN
- Basic static load rating: 117 kN
NSK 6222
NSK 6222 details
| model | 6222 |
|---|---|
| d | 110 mm |
| D | 200 mm |
| B | 38 mm |
| rmin. | 2.1 mm |
| Cr |
144000 N 14700 kgf |
| C0r |
117000 N 11900 kgf |
| Limiting speeds | 2800 min-1 (Grease) |
| Limiting speeds | 3400 min-1 (Oil) |
| f0 | 14.3 (Factor) |
| da min | 121.0 mm |
| da max | 134.0 mm |
| Da | 189.0 mm |
| ra | 2.0 mm |
| Mass | 4.450 kg (approx.) |
NSK 6222 bearing cross reference
302K
110 mmx 200 mmx 38 mm
301K
110 mmx 200 mmx 38 mm
62207-2RS-C3
110 mmx 200 mmx 38 mm
62306-2RS-C3
110 mmx 200 mmx 38 mm
63005-2RS-C3
110 mmx 200 mmx 38 mm
62205-2RS-C3
110 mmx 200 mmx 38 mm
62304-2RS-C3
110 mmx 200 mmx 38 mm
62204-2RS-C3
110 mmx 200 mmx 38 mm
63003-2RS-C3
110 mmx 200 mmx 38 mm
62303-2RS-C3
110 mmx 200 mmx 38 mm
63002-2RS-C3
110 mmx 200 mmx 38 mm
